Thermoplastic polyurethane tape with very good isolating behavior and excellent mechanical properties and good thermal characteristics

Possible Thickness:
MT 102: 0.250mm (EOL)
MT 103: 0.280mm (EOL)

Download: Keratherm MT 102  (EOL) &  MT 103  (EOL) Datasheet
Click to Get a Quote for Keratherm MT 103!

Advantages

  • Very good price/performance ratio
  • Very good mechanical properties
  • Very good insulating properties

Applications

  • Automotives
  • High voltage technology
  • Power converters (AC-DC,DC-DC)

Delivery Forms

  • bulk good
  • optional with single sided adhesive
  • already punched geometries
  • Property Symbol Unit MT 102 (EOL) MT 103 (EOL)
    Color blue red
    Thermal Properties
    Thermal Resistance Rth K/W 0.53 0.39
    Thermal Impedance Rti °Cmm²/W
    Kin²/W
    200
    0.28
    156
    0.21
    Thermal Conductivity λ W/mK 1.1 1.8
    Electrical Properties
    Breakdown Voltage Ud;ac kV 10 10
    Dielectric Breakdown Ed;ac kV/mm 25 25
    Volume Resistivity Ocm 2.2×1010 4.7×1010
    Dielectric Loss Factor tan d 1 1.0×10-3 1.0×10-3
    Dielectric Constant er 1 2.7 2.6
    Mechanical Properties
    Overall Thickness (±10%) mm 0.250 0.280
    Hardness Shore A 65 – 75 70 – 80
    Tensile Strength N/mm² 2.0 2.0
    Elongation % > 1000 200
    Physical Properties
    Density g/cm3 1.87 1.88
    Application Temperature °C -40 to +125 -40 to +125
    Flame Class UL 94V-0 94V-0
