Kerafol’s PCM 16125C is an excellent alternative for thermal pastes. The PCM changes its aggregate state from solid to liquid at a certain melting temperature. The result is a thermal interface material with a very low bond line. Furthermore, the PCM compensates irregularities between the electronic component and the heat sink, thereby optimizing the contact between the surfaces and increasing the heat transfer.

Possible Thickness: 50 – 250 µm

Download: Keratherm PCM16125C Datasheet (pdf)
Click to Get a Quote for Keratherm PCM16125C!

Applications

  • notebooks
  • desktop CPU’s
  • IGBT units
  • Properties Symbol Unit PCM 16125C
    Color Titanium Blue
    Viscosity Brookfield K/P*
    (Temperature dependent; dried area)
    Pas 400/creamy (@40°C)
    200 (@50°C)
    120 (@60°C)
    80 (@80°C)
    50 (@100°C)
    Thermal conductivity λ W/mk >3.5
    Dielectric breakdown Ed KV/mm >1
    Operating temperature °C -40 to +120
    Softening interval °C 52-54
    Possible layer thickness µm 50-250
    Post-curing time
    (40°C @ 250 µm)**
    h 18-24

    * Sheare rate λ 4.6s-1
    ** This time is valid for natural convection. If there is ventilation, the time curing time is lower
